Detailed Specs

General

• Dimensions: 84 x 50 x 16.6mm
• 3.31” (L) x 1.97” (W) x 0.65” (H)
• Weight: 74g (2.61oz)
• Backup Battery: Li-Polymer, 190 mAh
• Standby Time:
  • Without reporting: 40 hours
  • 5 minutes’ reporting: 30 hours
  • 10 minutes’ reporting: 36 hours
• Operating Voltage: 8V to 32V DC
• Operating Temperature: -30℃ ~ +80℃
• Storage Temperature: -40℃ ~ +80℃
• Waterproof: IP67 compliant
• BLE 5.1 Support: BLE 5.1 protocol
• Buffer Messages: Up to 10,000 buffer messages
• Zero Power Consumption: Vehicle battery drain prevention when ignition is off. Typical <0.25mA@12V

Advanced

LTE Specifications

• Operating Band:
  • LTE Cat M1/NB2
  • Cat M1: B1/B2/B3/B4/B5/B8/B12/B13
    B18/B19/B20/B25/B27/B28/
    B6/B85
  • Cat NB2: (*Cat NB1 is available in Brazil)
    B1/B2/B3/B4/B5/B8/B12/B13
    B18/B19/B20/B25/B28/B66/B71/B85
• Data Transmission:
  • eMTC (DL): 348 Kbps
  • eMTC (UL): 1.08 Mbps
  • NB2 (DL): 121 Kbps
  • NB2 (UL): 150 Kbps
  • NB1 (DL): 74.1 Kbps
  • NB1 (UL): 101 Kbps

GSM Specifications

• Frequency: 850/900/1800/1900 MHz
• Data Transmission:
  • Edge: 296 Kbps (DL) / 236.8 Kbps (UL)
  • GPRS: 107 Kbps (DL) / 85.6 Kbps (UL)

GNSS Specifications

• GNSS Type: MTK GNSS receiver
• Sensitivity:
  • Autonomous: -148 dBm
  • Hot start: -163 dBm
  • Tracking: -165 dBm
• Position Accuracy (CEP):
  • Autonomous: < 2.5m
• TTFF (Open Sky):
  • Cold start: 31s average
  • Warm start: 28s average
  • Hot start: 1s average

Interfaces

• Digital Inputs:
  • 1 positive trigger input for ignition detection and other applications
  • 1 negative trigger input
• Digital Output: 1 digital output, open drain, 150 mA max drive current
• Cellular Antenna: Internal only
• GNSS Antenna: Internal only
• BLE Antenna: Internal only
• LED Indicators: GNSS, CEL
• Micro USB Interface: Used for upgrading and debugging

Air Interface Protocol

• Transmit Protocol: TCP, UDP, SMS
• Power Supply Monitoring: Alarm status reporting of the external power
• Scheduled Report: Report position and status based on preset time intervals, distance, mileage, or a combination of these settings
• Geo-fences: Geo-fence alarm and parking alarm, support up to 20 internal geo-fence regions
• Speed Alarm: Flexible speed monitoring for unusual speed alarm
• Tow Alarm: Alarm for tow event in ignition-off state
• Remote Control: OTA control of digital outputs
• SOS Alarm: Alarm message report triggered by panic button in emergency situation
• Driving Behavior Monitoring: Aggressive driving behavior detection, including harsh braking, acceleration, etc.
• Configuration Tamper Protection: Critical configuration such as server information are encrypted to avoid unauthorized change
• Virtual Ignition Detection: Based on voltage and accelerometer
• Jamming Detection: Alarm based on jamming detection
